技术规格样本
|
|
Weights (pounds) |
G40QG |
G40QH |
G40TF |
Gross Vehicle Weight Rating - (GVWR) (lbs.) (1) |
32,000 |
32,000 |
32,000 |
Gross Combined Weight Rating - (GCWR) (lbs.) (2) |
42,000 |
42,000 |
42,000 |
Gross Axle Weight Rating - (GAWR front) (lbs.) (3) |
12,000 |
12,000 |
12,000 |
Gross Axle Weight Rating - (GAWR rear) (lbs.) (3) |
20,000 |
20,000 |
20,000 |
Base Weight (lbs.) (4) |
28,680 |
28,680 |
28,680 |
Net Carrying Capacity - (NCC) (lbs.) (5) |
3,320 |
3,320 |
3,320 |
Hitch Rating Weight (lbs.) * |
10,000 |
10,000 |
10,000 |
Tongue Weight (lbs.) * |
1,000 |
1,000 |
1,000 |
|
Measurements |
G40QG |
G40QH |
G40TF |
Wheel Base |
276" |
276" |
276" |
Overall Length (6) |
42'-3" |
42'-3" |
42'-3" |
Overall Height w/AC |
12'-3" |
12'-3" |
12'-3" |
Overall Width (7) |
101" |
101" |
101" |
Interior Height |
6'-7" |
6'-7" |
6'-7" |
Interior Width |
96" |
96" |
96" |
|
Tank & Liquid Capacities (gallons) |
G40QG |
G40QH |
G40TF |
Fresh Water Tank |
105 |
105 |
105 |
Grey Water Holding Tanks |
60 |
60 |
60 |
Black Water Holding Tanks |
60 |
60 |
60 |
LPG Tank (8) |
38 |
38 |
38 |
Water Heater |
12 |
12 |
12 |
Fuel Tank |
150 |
150 |
150 |
|
| |
|
|
|
| |
|
|
|
|
|
